E40 HQL LED bulb 38W = 125w 2700K Ledvance
HPD LED LEDV HQL LED Fil Verre 360 ° E40 38 W 5400 lm Ra80 2700 KIncluding 0.29 € for eco-contribution
The French flag indicates the current stock in our warehouse in France, therefore immediately available. If this indicates "0", we will have to restock from our supplier according to your order and this implies an approximate time shown below in "shipping day".
Several of our suppliers tell us their stock status once a day and we communicate them after the European flag. This provides more information on restocking times.
Some suppliers do not wish to communicate their stocks beyond 200 pcs.
Some suppliers do not communicate their stocks.
Product advantages
Same design as traditional HQL lamps with frosted glass and ellipsoid bulb
Full use of the existing luminaire reflector thanks to a 360 degree beam angle
Saves up to 78% energy by replacing mercury vapor lamps (HQL)
Instant ignition
Application areas
streets
lighting area
Pedestrian zones
Parks
Outdoor use only in suitable fixtures
Product Features
Replacement of HQL: suitable for operation with conventional power supply for HQL or on direct 230 V connection
Replacement for other HID: Suitable for operation with line voltage without control gear
Power factor: 0.9
Type of protection: IP65
Surge protection: up to 2 kV (L-N)
Safety tips
Not suitable for use with primer
Capacitor operation can cause a decrease in system power factor.
When installed horizontally, the tc point of the lamp is located on the upper side of the lamp.
Not recommended for use in narrow fixtures and fixtures with narrow reflectors.
Only suitable for temperatures up to 50°C inside the luminaire. Not recommended for use in small luminaires and in luminaires with small reflectors.
Data sheet
- FAMILY
- Lampes
- Technology
- LED
- Power supply
- French sector
HQL Ferromagnetic Ballast - Energy efficience label
- D
- Base
- E40
- Switching cycle
- 100000
- Diameter
- 90.00 mm
- Average nominal lifespan
- 25000 H
- Lamp efficacy
- 142 Lm/W
- Equivalency
- 125
- Manufacturer
- LEDVANCE
- Power factor
- 0.90
- Luminous flux
- 5400 Lm
- Form
- Ovoïde
- Frequency
- 50/60
- Manufacturer warranty (year)
- 5
- Dimmable
- Non
- IP classification
- 65
- Color rendering indice (CRI)
- 80
- Current
- 0.16 A
- Overall lenght
- 202.00 mm
- Certifications
- CE
RG 1 Photobio 62471 - Operating range
- -20 +50 °C
- Power
- 38 w
- Glass shade
- Opale
- Color temperature
- 2700 K
- Input voltage
- 220 v
- Input voltage type
- AC
- Angle
- 360.00 °
- Weight
- 0.21 Kgs
- Energy consumption
- 38.00 Kwh/1000H
- Eprel
- 371168
- Length : 35.6 cm
- width : 24.2 cm
- height : 26.3 cm
