LED DRIVER VALUE Constant Voltage 24v 150w Ledvance
DRIVER LED VALUE TENSION Constante 24 V 150 WIncluding 0.10 € for eco-contribution
The French flag indicates the current stock in our warehouse in France, therefore immediately available. If this indicates "0", we will have to restock from our supplier according to your order and this implies an approximate time shown below in "shipping day".
Several of our suppliers tell us their stock status once a day and we communicate them after the European flag. This provides more information on restocking times.
Some suppliers do not wish to communicate their stocks beyond 200 pcs.
Some suppliers do not communicate their stocks.
Product advantages
Perfectly suited for 24 V LED flexible strips
Excellent price/performance ratio
3 year warranty
Quick and simple installation
Good efficiency and reliability
Product features
Available in 30W, 60W, 120W and 150W
Integrated cable clamp for independent installation
Service life: up to 35,000 h (at maximum temperature tc)
Protection type: IP20
Low current ripple rate < 5%
Supply voltage: 220 to 240 V,
Operating frequency: 50/60 Hz
Operation with less than 60 V: Safety Extra Low Voltage (SELV)
Protection against overheating, overload, short circuits and reversible open circuits
Application areas
Bay lighting, even in tight spaces
Wallwasher effect lighting in living rooms, dining rooms, bedrooms and entrances
For interior SELV installations
Offices, shopping centers, hospitals, restaurants, hotels
Data sheet
- FAMILY
- Accessoires
- Emplacement
- Capoté
- Technology
- LED
- Equipment
- LED Driver
- Power supply
- French sector
- Electrical protection class
- II
- Average nominal lifespan
- 35000 H
- Manufacturer
- LEDVANCE
- Power factor
- 0.9
- Frequency
- 50/60
- Product line
- Tension Constante (Volts)
- Dimmable
- Non
- Height
- 30.50 mm
- IP classification
- 20
- Width
- 45.00 mm
- Overall lenght
- 268.00 mm
- Certifications
- CE
- Operating range
- -20 +45 °C
- Power
- 150 w
- Input voltage
- 220-240 v
- Output voltage
- 24
- Output voltage type
- DC
- Plage d'intensite de sortie
- 6250
- Weight
- 0.431 Kgs
- Eprel
- 1213609
- Length : 30.7 cm
- width : 29.6 cm
- height : 12.2 cm
